Fixture, Tooling, Test Stand Design & Manufacturing Services

Comprehensive Manufacturing Services

Our manufacturing group offers a wide range of services from design, manufacturing, fixturing, assembly, pressure testing and CMM inspection services. We often develop outlines for part traceability and work instructions for assembly and testing processes with step-by-step visual reference.

The image shows a complex assembly of metal pipes and components, likely part of an industrial or mechanical system. The setup includes several bent metal tubes connected to various fittings and brackets, mounted on a metallic grid or frame.
The image shows a metal workbench with various tools and components. There is a white plastic component mounted on a metal fixture with three brass fittings protruding from it. The fixture is secured to the workbench with a C-clamp. On the left side of the image, there are tools including pliers, markers, and screws placed on a red cloth.
The image shows two identical metal frames with multiple circular cutouts, placed on a wooden pallet. The frames appear to be part of an industrial or mechanical assembly, possibly for holding or aligning components.
A factory scene showcasing a machine under construction, with workers and equipment actively engaged in the assembly process.
A 3D rendering of a complex machine showcasing various interconnected parts and components in intricate detail.
The image shows a metal fixture or jig mounted on a granite surface plate. The fixture appears to be used for holding or aligning parts during machining or inspection processes. It has multiple holes and markings, including some red markings, and is secured with bolts to the base.
The image shows a metal mechanical component mounted on a black surface. The component appears to be part of a larger machine or assembly, featuring several circular holes and a lever mechanism with a handle.
The image shows a series of identical, machined metal parts arranged in a row on a reflective surface. The parts appear to be precision-engineered components with multiple holes and cutouts, likely for mechanical or industrial use. The metal has a polished finish, and the parts are aligned in an orderly fashion.
The image shows a large number of identical metallic components arranged in a grid pattern. Each component appears to be cylindrical with a central hole and is placed on a flat surface. The components have a shiny, reflective finish, indicating they are likely made of metal.
The image shows a workspace in a mechanical or manufacturing workshop. There are several blue bins on the table containing various metal parts, such as screws and springs. In the foreground, there are two metal fixtures with red handles mounted on a metallic surface. The background includes more workbenches, tools, and machinery.
The image shows a metal fixture or jig on a workbench, likely used for holding and securing parts during machining or assembly. The fixture has two red-handled clamps and additional components to hold the part in place. There are blue bins in the background containing small parts, and a piece of brown paper with text is partially visible on the right side of the image.
The image shows a hand holding a Patmark engraving tool, which is being used to engrave or mark a metal component. Several similar metal components are lined up on a table in the background.
The image shows a series of metallic components arranged in rows on a surface. Each component appears to be cylindrical with flanges and mounting holes, and the openings are filled with crumpled brown paper.
The image shows several cylindrical metal components with multiple springs and bolts arranged on a flat surface. These components appear to be mechanical parts, possibly related to engines or machinery.
The image shows a laboratory or workshop setup with various equipment and tools. On the left side, there is a device with three pressure gauges mounted on top, labeled "ENGINE TEST PROGRAM - MURE." Below the gauges, there are several metallic components and pipes connected to the device. In the center of the image, there is a blue pegboard with tools hanging on it and some papers attached. To the right of this setup, there is another piece of equipment with a digital display showing "0.572 psi" and labeled "ETAMAX 128." Below this device, there are additional components including a can of WD-40 lubricant spray.
The image shows a mechanical setup with multiple valves and levers. There are five labeled valves at the top (W1, W2, K4, K1, K5) connected to a black bar. Below this bar are two additional components labeled H2 and K-1. At the bottom of the image, there are five red-handled levers attached to cylindrical components. The background has a patterned surface.
The image shows a precision fixture and tooling setup used for engine component testing. The setup includes a metal frame with two pressure gauges mounted on top, connected to various valves and hoses. Adjacent to the frame is a custom fixture designed to hold an engine manifold securely in place during testing. The entire assembly is situated on a metal mesh platform within an industrial test stand, surrounded by additional equipment and tools.
